TGM Series Super Pressure Trapezium Mill is the latest grinding mill. TGM Series Supper Pressure Trapezium Mill is researched and designed by our experts basing on long term experiences of mill research and development, and according to numbers of customers' using requirements and suggestions home and aboard. The TGM Series Super Pressure Trapezium Mill adopts our patented technologies, like trapezium working surface, flexible connection, roller linked pressure boost, etc. TGM Series Super Pressure Trapezium Mill has reached the advanced international level of powder making equipment manufacturing.

TGM Series Super Pressure Trapezium Mill can grind all kinds of non-flammable and non-explosive minerals with Moh’s hardness lower than 9 and humidity less than 6%，and TGM Series Super Pressure Trapezium Mill is widely used in metallurgy, manufacture of building materials, stone industry, minig industry, etc.

Table 1

Note:
1. Based upon limestone-grinding with 80% pass-through;
2. The final technical data are subject to the operation manual along with the machine.

Table 2

Firstly, large material is crushed into the size specified (powder or small material is no need to be crushed by Jaw Crusher, then transported into the hopper by bucket elevator vertically, and then fed into the main mill by electromagnetic vibrating feeder continuously and evenly. The ground fine powder in the main mill is carried out by the airflow from the blower, and then separated by the classifier above the main mill. The fine powers are blow into the cyclone collector, where separate with the airflow, and are poured out through the discharge valve as the final products and the rough stuff after the classifying will be recycled back into the grinding chamber for regrinding. The set’s airflow system is closely sealed up and circulated under condition of negative and positive pressure.
